| Work Height | 25’ 6” (7.77 m) | |
| Raised Platform Height | 19’ 6” (5.94 m) | |
| Lowered Platform Height | 30” (0.76 m) | |
| Overall Width | 31.5” (0.80 m) | |
| Overall Length | 54” (1.37 m) | |
| Stowed Height | 79.5” (2.0 m) | |
| Platform Width (Inside Dimension) | 27” (0.69 m) | |
| Platform Length (Inside Dimension) | 36” (0.91 m) | |
| Extension Deck (Roll Out) | 16” (0.41 m) | |
| Ground Clearance (Stowed) | 1” (2.54 cm) | |
| Ground Clearance (raised) | 3.5” (9 cm) | |
| Wheelbase | 44” (1.12 m) | |
| Weight | 2,440 lbs (1,107 kg) | |
| Gradeability | 25% | |
| Turning Radius (Inside) | 0 | |
| Turning Radius (Outside) | 55” (1.40 m) | |
| Lift Time (With Rated Load) | 26 sec | |
| Lower Time (With Rated Load) | 26 sec | |
| Drive Speed (Stowed) | 2 mph (3.0 km/h) | |
| Drive Speed (Raised) | 0.3 mph (0.5 km/h) | |
| Maximum Drive Height | Full Height | |
| Capacity | 350 lbs (159 kg) | |
| Capacity (Overall) | 350 lbs (159 kg) | |
| Local Floor Load (With Rated Load) | 148 psi (1,021 kPa) | |
| Overall Floor Load (With Rated Load) | 237 psf (11.3 kPa) | |
| Maximum # of Persons | 1 | |
| Wind Rating | 0 (Optional 1 @ 28 mph (12.5 m/s) | |
| Tire Type | Solid, N/M | |
| Tire Size | 10” x 4” (252 mm x 102 mm) |
Hours: 1861
